Fuwaytai

Descriptions

The Spray Valves are designed for precise spray applications of low
viscosity materials. Total control of the spray cycle is provided by
adjustable fluid flow and precise control of pre-spray, atomizing air and
post-spray with the TS500R Valve Controller. Normal maintenance is
simple and downtime is virtually eliminated with only one seal to replace.

The TS5540 Spray Valves come with FDA-Compliant 303 stainless steel
construction in both air cylinder and fluid housing. A field replaceable
Delrin® seat provides positive shut-off and extends life cycles. The
compact design and easy-mount threaded hole allow for easy integration
into automated applications.

Key Features:
• Consistent spray coverage with no overspray
• Positive shut-off
• Adjustable flow control
• Long life cycles

Typical Applications:
To spray fine mist of low viscosity fluids such as: conformal coating,
solvent, oil, etc.

TS5540-MS Microshot Spray Valve
The TS5540-MS spray valve is designed to spray low viscosity materials
through disposable dispensing tips. Spray patterns range from 0.18" -
0.60" (4.6mm-15mm) in diameter.
